Max 55SC Sailing Catamaran – Space, Performance
& Offshore Capability Redefined
“The Max 55SC sailing catamaran, also known as the Max 55SC catamaran by Max Cruise Marine, is a high-performance sailing multihull built for extended offshore cruising.” With generous interior volume, lightweight composite construction, and hybrid propulsion options, the Max 55SC offers unmatched comfort, efficiency, and range for serious sailors.
Designed for Space, Strength, and Stability at Sea

Designed for Space, Strength, and Stability at Sea
Spanning 16.8 meters in length and 8.5 meters in beam, the Max 55SC multihull offers expansive deck areas and customizable living quarters. With a shallow 1.4m draft thanks to mini keels, this yacht gives you access to anchorages that deeper vessels can’t reach—without compromising offshore capabilities.
-
Length overall (LOA): 16.8m
-
Beam overall (BOA): 8.5m
-
Draft: 1.4m (mini keel)
-
Displacement (light): 11,200 kg
- Bridge deck clearance: 0.95m
A Performance Catamaran Built for Offshore Adventures
A Performance Catamaran Built for Offshore Adventures
“Designed as a true offshore cruiser, the Max 55SC delivers the space, range, and security required for serious bluewater cruising…”
“The high-performance catamaran rig is optimized for long-range efficiency, making it an ideal multihull for circumnavigation or extended offshore sailing.”
Whether you’re sailing across oceans or cruising remote island chains, the Max 55SC is designed to deliver fast, responsive, and comfortable performance.
Sail Plan:
-
Mainsail: 98 m²
-
Jib: 62 m²
-
Code Zero (optional): 105 m²
-
Spinnaker (optional): 180 m²
The Max 55SC sails efficiently even in light winds, making it ideal for long-distance voyaging or liveaboard adventures.
Power, Efficiency, and Hybrid Propulsion Options
Power, Efficiency, and Hybrid Propulsion Options
The Max 55SC is equipped with twin 50hp engines for dependable motoring and maneuverability in any conditions. It also supports hybrid propulsion systems, including electric drives, solar arrays, and lithium battery banks—making it a future-ready catamaran for eco-conscious sailors.
Optional hybrid features include:
-
10kW electric drive motors
-
5kW generators
-
15kW Victron inverter system
-
4.8kW of solar with MPPT controllers
-
40kWh lithium battery bank with CAN bus
-
48V windlass and deck winches
-
DC/DC 48/12V conversion for onboard systems
Precision Built and Luxury Interiors
Why Choose the Max 55SC for Extended Cruising?
Precision-Built Using Advanced Materials
Max Cruise Marine uses cutting-edge resin infusion and CNC-cut composite materials to deliver a lighter, stiffer, and more durable multihull. The result is a multihull catamaran with exceptional strength-to-weight ratio, lower fuel use, and increased sailing performance.
Luxury Interiors Customized to Your Lifestyle
The Max 55SC offers versatile layout options and premium finishes throughout. Whether you want three or four cabins, an extended galley, or workspaces for long-term liveaboard life, you can tailor your Max 55SC to match your sailing ambitions.
-
Island queen and king berths
-
Ensuite bathrooms
-
Ergonomic navigation and control stations
-
Spacious saloon with panoramic views
-
Gourmet galley with modern appliances
Why Choose the Max 55SC for Extended Cruising?
-
Designed for global voyaging with ocean-rated stability
-
Massive storage and generous tankage for long passages
-
Efficient sail handling for short-handed crews
-
Light, strong, and fast hulls
-
Hybrid-capable systems for quiet, clean energy independence
Experience the Max 55SC Multihull Advantage
The Max 55SC truly lives up to its name: the ultimate multihull for extended cruising and offshore adventures. It blends sailing performance, spacious living, and advanced technology in a way few catamarans in its class can match.
Contact Max Cruise Marine to request a brochure, get pricing, or schedule a private walkthrough.
